ProductDetailsTechnical data
-
Nominal Voltage: 3~15V Maximum torque: 1.32mNm No load Speed: 13200rpm Stall Torque: 3.4mNm Outside Diameter: 13mm Length: 22.3mm -
Nominal Voltage: 3~24V Maximum torque: 2.5mNm No load Speed: 10800rpm Stall Torque: 14.4mNm Outside Diameter: 13mm Length: 34.4mm -
Nominal Voltage: 6~24V Maximum torque: 1.5mNm No load Speed: 14100rpm Stall Torque: 5.1mNm Outside Diameter: 16mm Length: 23.8mm -
Nominal Voltage: 3~48V Maximum torque: 4.4mNm No load Speed: 12200rpm Stall Torque: 37.3mNm Outside Diameter: 16mm Length: 40.8mm
-
Nominal Voltage: 6~12V Maximum torque: 8.6mNm No load Speed: 15300rpm Stall Torque: 42.5mNm Outside Diameter: 16mm Length: 40.8mm -
Nominal Voltage: 6~36V Maximum torque: 5mNm No load Speed: 10900rpm Stall Torque: 14mNm Outside Diameter: 22mm Length: 24.2mm -
Nominal Voltage: 6~48V Maximum torque: 7mNm No load Speed: 7430rpm Stall Torque: 24.4mNm Outside Diameter: 22mm Length: 31.9mm -
Nominal Voltage: 12~24V Maximum torque: 11mNm No load Speed: 12000rpm Stall Torque: 62.3mNm Outside Diameter: 22mm Length: 31.9mm -
Nominal Voltage: 12~24V Maximum torque: 9mNm No load Speed: 10000rpm Stall Torque: 36.4mNm Outside Diameter: 23mm Length: 31.9mm -
Nominal Voltage: 9~48V Maximum torque: 28.1mNm No load Speed: 7570rpm Stall Torque: 126.8mNm Outside Diameter: 23mm Length: 46.9mm
